StarTech ESATAPLATE2.com 2 Port SATA to eSATA Slot Plate BRacket - eSATA slot bRacket SATA to eSATA plate SATA to eSATA bRacket View larger

StarTech ESATAPLATE2 2-Port SATA to eSATA Slot Plate Bracket

ESATAPLATE2

New

In Stock

StarTech 2-Port SATA to eSATA slot plate bracket for easy external SATA connections.

×




$7.50

Detailed Specifications

StarTech ESATAPLATE2 2-Port SATA to eSATA Slot Plate Bracket

Overview :

The StarTech ESATAPLATE2 is a 2-Port SATA to eSATA slot plate bracket that allows you to connect internal SATA drives to external eSATA devices. This convenient bracket transforms two internal SATA ports into two external eSATA ports, enabling faster and more accessible connections for your external storage devices. The ESATAPLATE2 is designed for easy installation, fitting into any standard expansion slot on your desktop PC or server, making it ideal for data backup, transferring large files, or expanding storage capabilities:The StarTech ESATAPLATE2 2-Port SATA to eSATA slot plate bracket adds two external eSATA ports to your desktop PC or server by connecting to the internal SATA ports. This bracket allows for easy connection of eSATA-compatible external storage devices, providing fast data transfer speeds and convenient access. It’s a simple yet highly effective solution for expanding your storage capacity or enhancing data transfer efficiency in professional or personal computing environments. Designed for easy installation, the ESATAPLATE2 fits into a standard expansion slot for immediate use.

Key Features:

  • Converts 2 internal SATA ports to 2 external eSATA ports
  • Allows for easy connection of external eSATA storage devices
  • High-speed eSATA interface for faster data transfer rates
  • Fits into a standard PCI expansion slot for simple installation
  • Ideal for data backup, storage expansion, and file transfers
  • Compatible with SATA I, II, and III ports
  • Supports transfer rates up to 6Gb/s
  • Durable and reliable design for long-term use

Specifications :

AttributeSpecification
Part Number ESATAPLATE2
Product Type SATA to eSATA Slot Plate Bracket
Brand StarTech
Port Count 2 x eSATA (External)
Connector Type 2 x eSATA (Female) to 2 x SATA (Male)
Cable Length 17.7 inches (45 cm)
Bracket Type Standard Expansion Slot Bracket
Data Transfer Rate Up to 6 Gb/s (SATA III)
Compatibility SATA I, II, and III compliant
Material Steel (Bracket) / Plastic (Connectors)
Mounting Type Fits into any standard PC case expansion slot
Supported Devices External SATA drives, eSATA enclosures
Connector Plating Nickel
Operating Temperature 0°C to 70°C (32°F to 158°F)
Storage Temperature -25°C to 85°C (-13°F to 185°F)
Compliance RoHS compliant
Weight 0.06 lbs (27 g)
Warranty Lifetime Warranty
