Ruckus ICX7450-48P-E-RMT3 48 Port PoE+ Switch with 4x10G SFP+ View larger

Ruckus ICX7450-48P-E-RMT3 48-Port 1GbE PoE Switch with 4x10G SFP

ICX7450-48P-E-RMT3

New

Ruckus ICX7450-48P-E-RMT3 48-port Gigabit PoE switch with Layer 3 routing for high-performance
×




Detailed Specifications

Ruckus ICX7450-48P-E-RMT3 48-Port 1GbE PoE Switch with 4x10G SFP

Overview :

The Ruckus ICX7450-48P-E-RMT3 is a high-performance 48-port Gigabit PoE switch designed for demanding enterprise environments. With advanced Layer 3 routing capabilities and a robust PoE power budget, this switch is ideal for powering and connecting various network devices, including IP cameras and wireless access points. Its scalable design and reliable performance make it suitable for large-scale network deployments.

Key Features :

  • 48 x Gigabit PoE ports
  • Advanced Layer 3 routing with IPv4 and IPv6 support
  • High PoE power budget for extensive device powering
  • Scalable with stacking support for up to 12 switches
  • Energy-efficient design with low power consumption
  • Secure network management with multiple protocols
  • Jumbo frame support for efficient data transfers
  • Comprehensive Quality of Service (QoS) features
  • Redundant power supplies for enhanced reliability
  • Enterprise-grade security features

Technical Specifications :

SpecificationDetail
Model ICX7450-48P-E-RMT3
Product Type Ethernet Switch
Ports 48 x Gigabit PoE
Layer Support Layer 2 and Layer 3
Switching Capacity 960 Gbps
Forwarding Rate 714 Mpps
Stacking Support Yes, up to 12 switches
Jumbo Frame Support Yes (up to 9,216 bytes)
Power Supplies Optional redundant power supply
PoE Power Budget High PoE power budget
VLANs Up to 4,094 VLANs
Security 802.1x, ACLs, DHCP Snooping, IP Source Guard
Management SNMP, CLI, Web-based, RMON, Telnet
QoS Advanced QoS with 8 queues per port
Dimensions 17.4 x 1.73 x 15.7 inches (WxHxD)
Weight 13.5 lbs
Power Consumption 210W (max)
Operating Temperature 0°C to 45°C
