Ruckus ICX7650-48ZP E2 Switch - Advanced Managed Network Switch View larger

Ruckus ICX7650-48ZP E2 Switch 48-Ports PoE 1x PSU L3 Managed Ruckus 24XMG

ICX7650-48ZP

New

Ruckus ICX7650-48ZP 48-Port PoE Layer 3 switch with 10GbE uplinks and 1500W power budget.
×




Detailed Specifications

Ruckus ICX7650-48ZP E2 Switch 48-Ports PoE 1x PSU L3 Managed Ruckus 24XMG

Overview :

Elevate your network infrastructure with the Ruckus ICX7650-48ZP E2 Switch, designed to deliver exceptional wired connectivity and network management. This versatile switch seamlessly integrates with both wired and wireless technologies, offering a range of fixed form-factor switches engineered to streamline network configuration and administration. By fostering interoperability and bolstering security measures, the ICX family simplifies setup, management, and troubleshooting tasks, ensuring efficient network operations. Whether deployed in small-scale or enterprise environments, these switches provide reliability, performance, and agility to meet evolving network demands and deliver outstanding customer experiences.

Key Features:

  • 48 ports with PoE+ capability
  • Layer 3 managed switch
  • Gigabit Ethernet, 10 Gigabit Ethernet, and 40 Gigabit Ethernet support
  • Stackable design for scalability
  • Redundant power supply support
  • Modular expansion slots for flexible configuration
  • Rack-mountable form factor for easy installation

Technical Specifications :

SpecificationDetail
Model ICX7650-48ZP
Port Count 48x 1/10GbE PoE+ Ports
Product Type Ethernet Switch
Layer Layer 3
Switching Capacity 1.08 Tbps
Forwarding Capacity 810 Mpps
Max Port Speed 10GbE
PoE Power Budget 1500W
Stacking Capability Up to 12 switches
Latency 600 ns
Uplink Ports 6x 40GbE or 2x 100GbE
Power Supply Redundant
Power Consumption 480W (base unit)
Cooling System Front-to-back airflow
Dimensions 1.72 x 17.32 x 18.11 in (HxWxD)
Weight 25 lbs (11.34 kg)
Operating Temperature 0°C to 45°C
Storage Temperature -40°C to 70°C
Humidity Range 10% to 95% non-condensing
Advanced Security MACsec, ACLs
Virtualization Support VXLAN, VRF
Management Options CLI, SNMP, Web UI
Standards Supported IEEE 802.3, 802.1Q, 802.3at, 802.3ad
