Ruckus Wireless ICX7650-48ZP-E LLC 48 Port 24XMG PoE+ Bundle 1PSU View larger

Ruckus ICX7650-48ZP-E Wireless LLC 48 Port 24XMG PoE Bundle 1PSU

ICX7650-48ZP-E

New

Ruckus ICX7650-48ZP-E 48-Port Layer 3 PoE switch with 1/10GbE ports and 1500W power
×




Detailed Specifications

Ruckus Wireless ICX7650-48ZP-E LLC 48 Port 24XMG PoE+ Bundle 1PSU

Overview :

The Ruckus ICX7650-48ZP-E is a robust and scalable 48-port Layer 3 switch designed for high-performance networking. It supports PoE+ on all ports, delivering up to 1500W of power, ideal for connecting and powering devices like IP phones, security cameras, and wireless access points. This switch offers advanced Layer 3 routing capabilities, ensuring seamless data transfer and high availability for modern enterprise environments. With its stackable architecture and high port density, the ICX7650-48ZP-E is perfect for organizations looking to expand and future-proof their networks.

Key Features :

  • 48x 1/10GbE PoE+ ports
  • Layer 3 routing with advanced features
  • 1500W PoE power budget
  • Supports stacking up to 12 units
  • Switching capacity of 1.08 Tbps, forwarding rate of 714 Mpps
  • Redundant power options for enhanced reliability
  • 10GbE and 40GbE uplink support
  • VXLAN, VRF support for network segmentation
  • Front-to-back airflow for efficient cooling
  • Easy management through CLI, SNMP, and web interface

Technical Specifications :

SpecificationDetail
Model ICX7650-48ZP-E
Port Count 48x 1/10GbE PoE+ Ports
Layer Layer 3
Switching Capacity 1.08 Tbps
Forwarding Capacity 714 Mpps
Max Port Speed 10GbE
PoE Power Budget 1500W
Stacking Capability Up to 12 units
Latency 600 ns
Power Supply Redundant
Power Consumption 400W (base unit)
Cooling System Front-to-back airflow
Dimensions 1.72 x 17.32 x 18.11 in (HxWxD)
Weight 24 lbs (10.9 kg)
Operating Temperature 0°C to 45°C
Storage Temperature -40°C to 70°C
Humidity Range 10% to 95% non-condensing
Advanced Security MACsec, ACLs
Virtualization Support VXLAN, VRF
Management Options CLI, SNMP, Web UI
Standards Supported IEEE 802.3, 802.1Q, 802.3at, 802.3ad
