TRENDnet TEG-MGBSX Mini-GBIC Multi-Mode SX Module View larger

TRENDnet TEG-MGBSX Mini-GBIC Multi-Mode SX Module

TEG-MGBSX

New

TRENDnet TEG-MGBSX Mini-GBIC Multi-Mode SX Module
×




Detailed Specifications

TRENDnet TEG-MGBSX Mini-GBIC Multi-Mode SX Module

Overview :

TRENDnet's SFP Multi-Mode LC Module, model TEG-MGBSX, are compatible with standard SFP slots found on network switches and fiber media converters. The Multi-Mode SFP LC module is equipped with a duplex LC fiber connection interface, and supports gigabit multi-mode fiber connections for long distance networking applicationsThe Trendnet TEG-MGBSX Mini-GBIC Multi-Mode SX Module (Version 2.0R) is engineered to be compatible with standard Mini-GBIC slots on most switches. It's an LC Type module for a multi-mode fiber and spans distances of up to 1,804.5' (550 m). The module features a single 1000 Mbps-SX LC-Type Mini-GBIC connector. It complies with IEEE 802.3z Gigabit Ethernet and Fiber Channel Standards.

Specifications :

Part Number  TEG-MGBSX
Product Name Mini GBIC Multi-mode SX Module
Product Type SFP (mini-GBIC)
Ethernet Technology Gigabit Ethernet
Media Type Supported Optical Fiber
Total Number of Ports 1
TAA Compliant Yes
Form Factor Hot-pluggable
Network Technology 1000Base-SX
Product Condition New
Fiber Mode Supported Multi-mode
Country of Origin Taiwan
Height 3"
Width 3"
Depth 5"
Connector Type LC
Product Model TEG-MGBSX
Application / Usage Data Networking
Maximum Distance Supported 1804.46 ft
Interfaces / Ports Details 1 x LC Duplex 1000Base-SX
Limited Warranty 3 Year Lifetime
NDAA Compliant Yes
Input Voltage 3.3 V DC
