HPE Aruba S4A50A CX 8325P 32port QSFP28 40G/100G Switch with 2xDC PSU View larger

HPE Aruba S4A50A CX 8325P 32port QSFP28 40G/100G Switch with 2xDC PSU

S4A50A

New

HPE 32-port of 40/100G switch with 6 fans and 2 DC power supplies installed with back-to-front airflow
×




Detailed Specifications

HPE Aruba S4A50A Ethernet Switch

Overview :

The HPE Aruba S4A50A CX 8325P is a high-performance networking switch designed for modern data centers and campus environments. It features 32 QSFP28 ports, supporting 40G/100G speeds, delivering robust connectivity for demanding applications. The switch offers a back-to-front airflow design, ensuring efficient cooling in rack-mounted setups. Equipped with 6 high-efficiency fans, it maintains optimal thermal performance under heavy workloads.

This bundle includes two DC power supplies, providing redundancy and reliability for uninterrupted operations. Built on the Aruba CX Switching Platform, it leverages advanced capabilities such as intelligent automation, programmability, and a cloud-native operating system. The CX 8325P is ideal for scalable network environments, enabling seamless integration with existing infrastructure.

Specifications :

FeatureSpecification
Power Consumption Max: 558 W (1907 BTU/hr), Idle: 135 W (462 BTU/hr)
Input Voltage -36 to -72 V DC
Ports 32 x 100G QSFP28
Switch Fabric Speed 6.4 Tbps
Switching Capacity 6.4 Tbps (switching), 2,000 Mpps (forwarding)
Stacking Capabilities Supports next-gen core, aggregation, and data center ToR/EoR needs
Throughput 2,000 Mpps
Memory and Processor 2.2 GHz CPU, 16 GB RAM, 64 GB SSD, 8 GB Flash, 32 MB Packet Buffer
Power Supply Field-replaceable, hot-swappable; supports up to 2 power supplies
Management Features CLI, SNMP v2c/v3, sFlow, RMON, PTP Class C (G.8275.1/.2)
