HPE Aruba S0G12A CX 8325P 32 Ports 40G/100G TAA Switch View larger

HPE Aruba S0G12A CX 8325P 32 Ports 40G/100G TAA Switch

S0G12A

New

HPE Aruba CX 8325P 32p 40G/100G TAA Switch
×




Detailed Specifications

HPE Aruba S0G12A Ethernet Switch

Overview :

The HPE Aruba S0G12A Networking CX 8325P is a powerful, TAA-compliant switch designed for high-performance and scalable data center and enterprise networking. With 32 QSFP28 ports that support both 40G and 100G Ethernet, this switch offers the bandwidth and flexibility needed for modern, data-intensive applications. Built with Aruba's CX Switching Architecture, it provides advanced networking capabilities, including Layer 2 and Layer 3 features, automation, and robust security. The CX 8325P is engineered for high availability with a redundant power supply, ensuring continuous uptime for critical workloads. Its flexible design and performance-driven features make it an ideal solution for organizations looking to future-proof their network infrastructure and handle demanding workloads efficiently.

Specifications :

FeatureSpecification
Power Consumption Max: 618 W (2110 BTU/hr), Idle: 143 W (489 BTU/hr)
Input Voltage 100–240 V AC
Ports 32 x 100G QSFP28
Switch Fabric Speed 6.4 Tbps
Switching Capacity 6.4 Tbps (switching), 2,000 Mpps (forwarding)
Stacking Capabilities Supports core, aggregation, and ToR/EoR data center requirements
Throughput 2,000 Mpps maximum
Memory and Processor 2.2 GHz CPU, 16 GB RAM, 64 GB SSD, 8 GB Flash, 32 MB Packet Buffer
Power Supply Field-replaceable, hot-swappable; supports up to 2 power supplies
Management Features CLI, SNMP v2c/v3, sFlow, RMON, PTP Class C (G.8275.1/.2)
