HPE Aruba S0G08A CX 8325P 32-Port 40G/100G Switch, Back-to-Front, 6xFan View larger

HPE Aruba S0G08A CX 8325P 32-Port 40G/100G Switch, Back-to-Front, 6xFan

S0G08A

New

HPE 32-port of 40/100Gbps switch with 6 fans and 2 DC power supplies installed
×




Detailed Specifications

HPE Aruba S0G08A Ethernet Switch

Overview:

The HPE Aruba S0G08A Networking CX 8325P is a high-performance, TAA-compliant switch designed to meet the demands of modern data center and enterprise network infrastructures. Offering 32 QSFP28 ports, it supports both 40G and 100G Ethernet, ensuring ample bandwidth for data-intensive applications. Its back-to-front airflow design is optimized for efficient cooling in dense environments, and the 6 fans, along with dual DC power supplies, provide redundancy and enhanced reliability. Built on Aruba's CX Switching Architecture, the CX 8325P delivers advanced Layer 2/Layer 3 features, network automation, and robust security capabilities. This switch is perfect for businesses looking to scale their network while maintaining performance, reliability, and energy efficiency.

Specifications Table

FeatureSpecification
Differentiator Supports a wide range of deployment models (1G, 10G, 25G, 40G, 100G). Supports PTP, Telco Class C, Synchronous Ethernet, GNSS for Telco Boundary Clock.
Power Consumption Max: 558 W, 1907 BTU/hr; Idle: 135 W, 462 BTU/hr
Input Voltage -36 to -72 volts DC
Ports (32) 100G QSFP28 ports
Switch Fabric Speed 6.4 Tbps
Switching Capacity 6.4 Tbps for switching, 2,000 Mpps for forwarding
Stacking Capabilities Designed for next-gen core and aggregation layers, ToR and EoR in data centers
Throughput 2,000 Mpps, maximum
Memory and Processor CPU: 2.2 GHz, 16 GB RAM, 64 GB SSD, 8 GB Flash, 32 MB Packet Buffer
Power Supply Field-replaceable, hot-swappable, up to 2 power supplies
Management Features Industry-standard CLI, SNMP v2c/v3, sFlow (RFC 3176), RMON, Precision Time Protocol (PTP Class C (G.8275.1/.2))
