StarTech.com SV231QDVIUA 2Port Quad Monitor Dual-Link DVI KVM Switch View larger

StarTech.com SV231QDVIUA 2Port Quad Monitor Dual-Link DVI KVM Switch

SV231QDVIUA

New

StarTech.com SV231QDVIUA 2Port Quad Monitor Dual-Link DVI KVM Switch
×




Detailed Specifications

StarTech.com SV231QDVIUA 2Port Quad Monitor Dual-Link DVI KVM Switch

OVERVIEW:

The SV231QDVIUA 2-Port Quad Monitor Dual-Link DVI USB KVM Switch allows 2 PCs, each with 4 DVI video outputs, to share monitors, 1 microphone and set of speakers, 1 keyboard and 1 mouse as well as an additional USB 2.0 peripherals such as an external hard drive, thumb drive, printer, or webcam.

The SV231QDVIUA Quad DVI KVM switch allows you to switch back and forth between 2 multi-DVI PCs at the touch of a button while maintaining professional-level video quality on all monitors at resolutions up to 2560x1600. The quad DVI switch also features an integrated USB hub port that allows USB 2.0 peripherals to be shared between attached systems - eliminating duplicate peripheral costs and offering the convenience of sharing stored data between PCs.

PLEASE NOTE: While both DVI-I (analog mode) and DVI-D (digital only) are supported by the KVM, both source PCs must output the same signal type for proper switching. It is recommended wherever possible to use DVI-D cables across all PC to KVM and KVM to Console connections. Please contact technical support for assistance identifying your source.

  • 1 - 2 Port Quad Display KVM
  • 2 - Rackmount Ears
  • 4 - Rubber Foot Pads
  • 1 - Universal Power Adapter (NA/UK/EU)
  • 1 - User Manual

Specifications:

Product Name 2 Port Quad Monitor Dual-Link DVI KVM Switch with Audio
Product Type KVM Switchbox
Maximum Video Resolution 2560 x 1600
USB Yes
DVI Yes
Number of Computers Supported 2
TAA Compliant Yes
Input Voltage Range 110V AC to 240V AC
Form Factor Desktop
Environmentally Friendly Yes
Graphic Mode WQXGA
Number of USB Ports 5
Number of DVI Ports 12
Country of Origin Taiwan
Height 1.7"
Width 17.2"
Depth 7"
Product Model SV231QDVIUA
Packaged Quantity 1
Product Color Black
Input Voltage 110 V AC

220 V AC
