CyberPower PR3000RTXL2UHVAN 3000VA 3000W Sine Wave High Voltage Ups View larger

CyberPower PR3000RTXL2UHVAN 3000VA 3000W Sine Wave High Voltage Ups

PR3000RTXL2UHVAN

New

CyberPower PR3000RTXL2UHVAN 3000VA 3000W Sine Wave High Voltage Ups

×




Detailed Specifications

CyberPower PR3000RTXL2UHVAN 3000VA 3000W Sine Wave High Voltage Ups

Overview :

The PR3000RTXL2UHVAN Smart App Sinewave UPS from CyberPower is a 2 RU rack/tower convertible device with line-interactive topology that provides battery backup and power protection via sine waveform output, plus surge protection for department servers, storage appliances, network devices, and telecom installations requiring Active PFC power source compatibility. It is built with a pre-installed SNMP card that provides remote system management and configuration via a standard web browser or network management system (NMS). It comes equipped with an output capacity of 3000 VA / 3000W, features an input voltage range of 131-302 VAC at 47-63 Hz, Automatic Voltage Regulation (AVR) to help correct minor power fluctuations without switching to battery power, and has integrated circuitry for EMI/RFI filters. This Smart App UPS provides an integrated LCD panel that rotates 90° for easier viewing and provides information on 47 different settings, including UPS stats, setup and control management, and testing options. This model also accepts the BP48VP2U03 Extended Battery Module (EBM) for expanded runtime during power outages. Also featured is an easy-to-access tool-free front panel, captive screws for battery panel access, and color-coded rear panel to make battery changes and installations simple and fast.

Specifications

Product Name 3000VA 3000W Sine Wave High Voltage Ups 3-Year
Product Type Line-interactive UPS
Receptacle Type NEMA 6-20R

NEMA L6-20R

Network (RJ-45) Yes
Product Family New Smart App Sinewave UPS
Backup / Run Time (Half Load) 10.70 Minute
Backup / Run Time (Full Load) 3.60 Minute
Load Capacity (VA) 3000 VA
Replaceable Battery Yes
Energy Star Yes
AVR Yes
Number of Battery & Surge Outlets 6
Product Color Black
Rack Height 2U
Plug / Connector Type NEMA L6-20P
Input Voltage Range 131 V AC - 302 V AC
Form Factor Rack/Tower
Network Management SNMP/HTTP Remote Monitoring
Waveform Type Sine Wave
Input Voltage 230 V AC
Battery Chemistry Lead Acid
Input Frequency 63 Hz
Battery Size 12V
Environmentally Friendly Yes
Battery Capacity 6000 mAh
Product Condition New
Maximum Operating Temperature 104°F (40°C)
Serial Port Yes
Number of Batteries 8
Battery Characteristics Sealed
EMI / RFI Noise Filter Yes
DC System Voltage 12 V DC
Energy Saving GreenPower UPS™ Bypass Technology
EPO Port Yes
USB (HID Compliant) Port Yes
Maximum Operating Elevation 10000 ft
Maximum Storage Elevation 50000 ft
Operating Humidity 0% - 95%
Number of Critical Load Outlets 2
Storage Temperature 5°F (-15°C) - 113°F (45°C)
Transfer Time 4 ms
Typical Battery Recharge Time 3 Hour
Receptacle Detail 4 x NEMA 6-20R

2 x NEMA L6-20R

Sound Emission (A-Weighted) 57.5 dB(A)
Country of Origin Philippines
Height 3.4"
Width 17.1"
Depth 24.8"
Output Frequency 60 Hz
Alarm Battery Mode

Low Battery

Overload

Overheat

Over Charge

Product Series New Smart App Sinewave UPS
Dataline Protection RJ-45
Load Capacity 3000 VA
Product Model PR3000RTXL2UHVAN
Overload Protection Yes
Surge Energy Rating 2430 J
Thermal Dissipation 35.20 W
Limited Warranty 3 Year
Output Voltage 200 V AC

208 V AC

220 V AC

230 V AC

240 V AC

Directly Connected Equipment Guarantee $400000Lifetime
