Synology RX2417sas NAS Expansion Unit Hard Drive View larger

Synology RX2417sas NAS Expansion Unit Hard Drive

RX2417sas

New

Synology RX2417sas NAS Expansion Unit Hard Drive
×




Detailed Specifications

Synology RX2417sas NAS Expansion Unit Hard Drive

Overview :

The Synology RX2417sas SAS/SATA Expansion Chassis provides twenty-four additional drive bays for your RackStation RS18017xs+ NAS enclosure, letting the host system hold more 2.5" SSDs or HDDs. Each of the bays has a hot-swappable drive tray for quick installation of a user-supplied drive and supports storage drives that feature a SAS or SATA interface. To run your drives reliably, two 500W power supplies and four 60mm fans are on board.

The RX2417sas comes with a SAS input port that connects to a host system's optional FS3017 expansion card; and a SAS output on the RX2417sas is available for accessing a second optional expansion chassis. This two-port design enables you to expand the RackStation RS18017xs+ NAS enclosure's storage capacity with up to seven RX2417sas chassis.

  • Plug-n-use design for seamless storage space upgrade
  • Online volume expansion on the fly
  • Redundant power supplies ensure service uptime
  • Fast rack fixing lock support with Synology RKS1317
  • Backed with Synology’s 5-year limited warranty & Synology Replacement Service (SRS)
  • Managed by Synology DiskStation Manager (DSM)

Specifications :

Product Name NAS Expansion Unit
Applied Models
  • FS3017*
  • FS2017
  • RS18017xs+
Note Connecting to a Synology FlashStation FS3017 requires the optional FS3017 Expansion Card (FXC17) to be installed on the host device. FS3017 Expansion Card is sold separately.
Storage
Drive Bay(s) 24
Compatible Drive Type
  • 2.5" SAS HDD
  • 2.5" SAS SSD
  • 2.5" SATA SSD
Hot Swappable Drive
RAID Management through Synology DSM
External Ports
SAS IN-port 1
SAS OUT-port 1
Appearance
Size (Height X Width X Depth) 88 mm x 482 mm x 724 mm
Weight 16.6 kg
Power
Power Supply Unit / Adapter 2 x 500W
AC Input Power Voltage 100V to 240V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 201.6 W (Access)
117.2 W (HDD Hibernation)
