Black Box EFNT010-001M-LCLC 10-Gigabit Multimode, 50-Micron Fiber Op View larger

Black Box EFNT010-001M-LCLC10-Gigabit Multimode Fiber Cable

EFNT010-001M-LCLC

New

1-meter 10-Gigabit multimode fiber cable with LC-LC connectors for high-speed data transfer
×




Detailed Specifications

Black Box EFNT010-001M-LCLC 10-Gigabit Multimode Fiber Cable

Overview :

The Black Box EFNT010-001M-LCLC 10-Gigabit Multimode Fiber Cable is designed for high-speed, reliable data transmission in demanding network environments such as data centers and enterprise LANs. Featuring OM3 multimode fiber and LC to LC connectors, it supports 10-Gigabit Ethernet over short distances up to 300 meters at 850 nm wavelength.This 1-meter cable is constructed with a low-smoke zero-halogen (LSZH) jacket, ensuring safety and minimizing emissions in case of fire. The aqua-colored jacket helps identify it as OM3, making it ideal for high-performance, high-density installations.The EFNT010-001M-LCLC is fully compliant with TIA/EIA-568-C.3 and IEEE 802.3ae standards, ensuring it meets industry requirements for quality and performance. It's suitable for applications like data centers, storage area networks (SANs), and high-bandwidth network backbonesThe Black Box EFNT010-001M-LCLC is a 1-meter, 10-Gigabit multimode fiber optic cable designed for fast, reliable data transmission. Featuring 50-micron fiber and LC-LC connectors, this cable is ideal for high-performance networking applications.

Technical Specifications :

AttributeSpecification
Part Number EFNT010-001M-LCLC
Product Type Multimode Fiber Optic Cable
Brand Black Box
Cable Type Fiber Optic
Data Rate 10-Gigabit Ethernet
Fiber Mode Multimode (OM3)
Cable Length 1 meter (3.28 feet)
Connector Type LC to LC (Duplex)
Core/Cladding Diameter 50/125 microns
Jacket Type LSZH (Low Smoke Zero Halogen)
Wavelength 850 nm
Maximum Data Transmission Distance 300 meters (984 feet) at 10 Gbps
Insertion Loss ≤ 0.3 dB
Return Loss ≥ 20 dB
Color Aqua
Compatibility 10G Ethernet, Fibre Channel, and other multimode applications
Compliance RoHS, TIA/EIA-568-C.3, IEEE 802.3ae
Temperature Range -20°C to 70°C (-4°F to 158°F)
Application High-speed data transmission, data centers, LANs, SANs
Fiber Count Duplex (two fibers)
Polish Type UPC (Ultra Physical Contact)
Weight 0.05 lbs (approx.)
Warranty Lifetime Warranty
