CyberPower PDU41104 24-Outlet 20A 200 to 240V Switched PDU View larger

CyberPower PDU41104 24-Outlet 20A 200 to 240V Switched PDU

PDU41104

New

CyberPower PDU41104 24-Outlet 20A 200 to 240V...

×




Detailed Specifications

CyberPower PDU41104 24-Outlet 20A 200 to 240V Switched PDU

Overview :

The CyberPower 24-Outlet 20A 200-240V Switched PDU, a 0 RU rackmount switched power distribution unit (PDU), provides 200-240V 20A output via 21 IEC-320 C13 and 3 IEC-320 C19 receptacles from a single NEMA L6-20P input power plug. The switched outlet receptacles can be managed over the network by using the CyberPower Management Console, a web browser, and the RJ45 Ethernet port for network connection, or locally from the Power Control display. The PDU41104 offers outlets that can be turned on, turned off, or recycled on demand. Outlets can be programmed to address a number of needs including remote rebooting of locked equipment, load shedding, power sequencing, and locking out unauthorized loads.

Power Distribution
Delivers AC power to servers, equipment, and connected devices via a power distribution unit.
Switch-Free Design
Safeguards against accidental power shutdown.
Switchable Outlets
Provides local and remote control for individual and multiple outlets. Local control can turn outlets off and on and disable unused outlets. Remote control can restart outlets, restart devices, turn outlets off or on, schedule power sequencing, and disable unused outlets.
CyberPower Management Console
Built into Switched PDUs, a CyberPower Management Console is a hardware interface. Users can remotely switch individual PDU outlets or circuits on and off, immediately or on a schedule, to power cycle connected equipment. The CyberPower Management Console monitors the incoming power and power draw from the PDU, sends notifications based on the power status, and logs events.
Remote and Local Monitoring
The user can track PDU vitals both offsite and onsite, and remote and local monitoring provides control to turn individual outlets or circuits on or off.

Specifications

Product Name Switched PDU 0U 200-240V/20A 24 IEC-320 21XC13/3XC19 3-Year Warranty
Manufacturer Part Number PDU41104
Product Type PDU
Phase Single Phase
Receptacle Type IEC 60320 C13

IEC 60320 C19
Product Family Switched PDU
PDU Type Switched
Remote Outlet Switching Yes
Mounting Orientation Horizontal/Vertical
Rack Height 0U/1U/2U
Plug / Connector Type NEMA L6-20P
Input Current 20 A
Length 1.9"
Mount Type Rack-mountable

Wall-mountable
Environmentally Friendly Yes
Output Voltage Range 200 V AC - 240 V AC
Network (RJ-45) Yes
Receptacle Detail 21 x IEC 60320 C13

3 x IEC 60320 C19
Plug / Connector Detail 1 x NEMA L6-20P
Country of Origin China
Height 65.5"
Width 2.2"
Product Series Switched PDU
Limited Warranty 3 Year
