Vertiv I10101 Geist PDU Basic 1u 20A 120V 10 5-20R View larger

Vertiv I10101 Geist PDU Basic 1u 20A 120V 10 5-20R

I10101

New

Vertiv I10101 Geist PDU Basic 1u 20A 120V 10 5-20R
×




Detailed Specifications

Vertiv I10101 Geist PDU Basic 1u 20A 120V 10 5-20R

Overview :

The Vertiv I10101 Geist PDU is a basic power distribution unit designed for standard rack-mount installations in data centers or server rooms. Here are its key specifications and features:

  1. Form Factor: It is a 1U (1.75 inches high) unit, making it compact and suitable for installations where rack space is limited.

  2. Power Rating: Rated for 20 amps at 120 volts, providing sufficient power capacity for connecting and distributing power to various IT and networking equipment.

  3. Outlets: Equipped with 10 NEMA 5-20R outlets, which are commonly used in North America for devices requiring up to 20 amps of power.

  4. Basic Functionality: Provides essential power distribution without advanced features like metering or remote management, making it straightforward to use and cost-effective.

  5. Reliability: Built with durable materials and designed to meet industry standards for reliability and safety in electrical distribution.

  6. Applications: Suitable for a wide range of applications, including small to medium-sized data centers, server rooms, network closets, and other IT environments requiring reliable power distribution.

Specifications :

Product Name Geist PDU Basic 1u 20A 120V 10 5-20R
Manufacturer Part Number I10101
Product Type PDU
Receptacle Type NEMA 5-20R
PDU Type Basic
Mounting Orientation Horizontal
Power Rating (Watt) 1900 W
Rack Height 1U
Plug / Connector Type NEMA L5-20P
Input Current 20 A
Mount Type Rack-mountable
Input Voltage 120 V AC
Output Voltage 120 V AC
Environmentally Friendly Yes
Receptacle Detail 10 x NEMA 5-20R
Plug / Connector Detail 1 x NEMA L5-20P
Country of Origin United States
Height 1.7"
Width 17"
Depth 8.5"
Product Model MN01X1R0-10D203- 2TL5A0H10-S
Limited Warranty 5 Year
Stock Details
Manufacturer Vertiv
Manuf Part# I10101
