Ruckus ICX7550-48P Wireless LLC ICX7550 48 PoE No PSU/Fan View larger

Ruckus Wireless LLC ICX7550-48P 48 PoE No PSU/Fan

ICX7550-48P

New

Ruckus ICX7550-48P 48-port PoE+ switch with Layer 3 routing for advanced network management
×




Detailed Specifications

Ruckus ICX7550-48P 48-Port PoE+ Switch Advanced Layer 3 routing with high PoE power

Overview :

The Ruckus ICX7550-48P is a high-performance 48-port PoE+ switch designed to support Layer 3 routing. Ideal for demanding network environments, it delivers advanced network management, high PoE+ power capabilities, and scalable performance, ensuring efficient power delivery and optimal connectivity.

Key Features :

  • 48 x Gigabit Ethernet ports with PoE+ support
  • Advanced Layer 3 routing capabilities for efficient network management
  • High PoE+ power budget for powering a wide range of devices
  • Energy-efficient design with low power consumption
  • High switching capacity for robust performance
  • Secure network management with various protocols
  • Comprehensive Quality of Service (QoS) features
  • Scalable with stacking support
  • Jumbo frame support for optimized data transfers
  • Enterprise-grade security features

Technical Specifications :

SpecificationDetail
Model ICX7550-48P
Ports 48 x Gigabit Ethernet with PoE+
Layer Support Layer 2 and Layer 3
Switching Capacity 960 Gbps
Forwarding Rate 714 Mpps
Stacking Support Yes, up to 12 switches
Jumbo Frame Support Yes (up to 9,216 bytes)
PoE+ Power Budget High PoE+ power budget
Power Supplies Optional redundant power supply
VLANs Up to 4,094 VLANs
Security 802.1x, ACLs, DHCP Snooping, IP Source Guard
Management SNMP, CLI, Web-based, RMON, Telnet
QoS Advanced QoS with 8 queues per port
Dimensions 17.4 x 1.73 x 15.7 inches (WxHxD)
Weight 13.4 lbs
Power Consumption 200W (max)
Operating Temperature 0°C to 45°C
