Ubiquiti UniFi Protect G4 Doorbell (UVC-G4-DoorBell) View larger

Ubiquiti UniFi Protect G4 Doorbell (UVC-G4-DoorBell)

UVC-G4-DoorBell

New

Ubiquiti UVC-G4-DOORBELL-US UniFi Protect G4 Video Doorbell
×




Detailed Specifications

Ubiquiti UVC-G4-DOORBELL-US UniFi Protect G4 Video Doorbell w/ Display, Motion Detection, & Two-Way Audio

Overview :

Ubiquiti UniFi UVC-G4-DoorBell Protect G4 Doorbell is a WiFi video UVC-G4-DoorBell doorbell with a built-in display and real-time two-way audio communication. The camera features a high-quality 5MP sensor with enhanced night vision. Image streams can be viewed in up to 1600x1200 (2MP) HD at 30 FPS. UniFi UVC-G4-DoorBell Protect G4 Doorbell includes a PIR sensor for instant motion detection alerts. Integration with UniFi Protect provides an easy-to-use interface. A UVC-G4-DoorBell Wi-Fi video doorbell that captures videos and allows you to communicate with visitors at the front door. It has a high-quality 5MP sensor with enhanced night vision and supports live streaming up to 1600x1200 (2MP) HD at 30 FPS. UVC-G4-DoorBell Along with an integrated light, built-in display to show greeting messages, and motion alert, this weather-resistant doorbell is the reliable sentinel that you can count on day and night, rain or shine.

Features

  • 1600x1200 (2MP) HD stream with night vision (UVC-G4-DoorBell)
  • Integrated entrance lighting
  • Real-time two-way audio with echo cancellation
  • Built-in display
  • Dual-band 802.11ac Wi-Fi
  • PIR motion detection sensor
  • Weather-resistant
  • UniFi Protect integration

Specifications :

Dimensions 118.3 x 46.8 x 25.8 mm (4.66 x 1.84 x 1.02")
Weight
Without mount
With flat wall mount
With 20° wedge mount
130 g (4.59 oz)
178 g (6.28 oz)
200 g (7.05 oz)
Enclosure material Polycarbonate
Mount materials Flat wall mount: aluminum alloy
20° wedge mount: polycarbonate
Weatherproofing IPX4
Sensor 5 MP CMOS sensor
Lens Fixed focal length
View angle H: 138°, V: 114°, D: 155°
Night mode Built-in IR LED illumination and IR cut filter
Video compression H.264
Resolution 1600 x 1200 (4:3)
Maximum frame rate 30 FPS
Processor specs Quad-core Arm® Cortex®-A53 based chip
Memory information 512 MB
Management interface UniFi Protect
Networking interface 802.11 ac Wi-Fi
Flash memory support 256 MB
Max. power consumption 12VA
Power requirements 16-24VAC, 20VA
Link/activity LED Yes
Button Factory reset
Mounting Flat wall/20° wedge (kits included)
Operating temperature -10 to 40º C (14 to 104º F)
Operating humidity 0 to 90% non-condensing
Certifications FCC, IC, CE
Microphone Yes (can be disabled in software)
Speaker Yes
UniFi OS application UniFi Protect
Mobile app UniFi Protect iOS and Android
