Black Box AVX-VGA-TP-TX-8 Mediacento VX 8 Port Transmitter View larger

Black Box AVX-VGA-TP-TX-8 VGA over Twisted Pair Transmitter

AVX-VGA-TP-TX-8

New

×




Detailed Specifications

Black Box AVX-VGA-TP-TX-8 8-Port VGA Transmitter

Overview :

The Black Box AVX-VGA-TP-TX-8 is an 8-port VGA transmitter designed for use with the Mediacento VX series, offering a flexible solution for video distribution in various environments. This device enables seamless transmission of high-quality VGA signals over twisted-pair cabling, making it ideal for applications that require distributing video signals to multiple displays or locations. With its robust design and ease of integration, the AVX-VGA-TP-TX-8 supports efficient video distribution in conference rooms, educational settings, and control centers. Its compatibility with the Mediacento VX system ensures a streamlined setup, while its advanced features facilitate reliable and high-performance video delivery.

Specifications :

Product Name Mediacento VX 8 Port Transmitter
Manufacturer Part Number AVX-VGA-TP-TX-8
Product Type Video Extender Transmitter
Maximum Operating Distance 984.25 ft
Number of Network (RJ-45) Ports 9
Product Family MediaCento
Media Type Supported Twisted Pair
Number of Input Devices Supported 1
Number of VGA Inputs 1
Connectivity Technology Wired
Graphics Modes WUXGA
Environmentally Friendly Yes
Maximum Video Resolution 1920 x 1200
Twisted Pair Cable Standard Category 5
Network (RJ-45) Yes
Number of VGA Outputs 1
VGA In Yes
VGA Out Yes
Transmitter Height 1.60"
Transmitter Width 6.75"
Transmitter Depth 4"
Transmitter Weight (Approximate) 1.60 lb
Country of Origin Taiwan
Product Line MediaCento
