MikroTik RBDynaDishG-5HacD-US DynaDish 5 US 5GHz Outdoor device View larger

MikroTik RBDynaDishG-5HacD-US DynaDish 5 US 5GHz Outdoor device

RBDynaDishG-5HacD-US

New

MikroTik RBDynaDishG-5HacD-US DynaDish 5 US 5GHz Outdoor device
×




Call For Price

---Please Select---

Detailed Specifications

MikroTik RBDynaDishG-5HacD-US DynaDish 5 US 5GHz Outdoor device

Overview :

The DynaDish 5 RBDynaDishG-5HacD-US is a new 802.11ac outdoor device with an integrated antenna. Compact in it’s design, it is a simple RBDynaDishG-5HacD-US and completely integrated product with everything you need to quickly install a reliable point-to-point link.

The DynaDish 5 is powered by a new 720MHz CPU from Qualcomm.

The antenna is a 8 degree 25dBi dish, RBDynaDishG-5HacD-US and it includes a precise alignment mount, RBDynaDishG-5HacD-US ideal for long range point to point wireless links.

  • The DynaDish 5 is a new RBDynaDishG-5HacD-US 802.11ac outdoor device with an integrated antenna. It is ideal for long distance point-to-point links
  • The DynaDish 5 is ideal for long distance point-to-point links
  • The DynaDish 5 is powered by a new 720MHz CPU from Qualcomm
  • CPU nominal frequency: 720 MHz; Size of RAM: 128 MB; Storage size: 16 MB; 10/100/1000 Ethernet ports: 1
  • PoE in: 802.3af/at; PoE in input Voltage: 11-60 V; Wireless 5 GHz number of chains: 2; Wireless 5 GHz standards: 802.11a/n/ac

Specifications :

Product code RBDynaDishG-5HacD-US
CPU Nominal Frequency 720 MHz
CPU Core Count 1
Size of Ram 128 MB
10/100/1000 Ethernet Ports 1
Wireless Built-in 5GHz 802.11ac, dual-chain
Antenna Gain 25dBi
Antenna Beam Width 8°
Wireless Chip Model QCA9882-BR4A-R
PoE In Yes
Supported Input Voltage 11V - 60V passive PoE or 802.3af/at with unshielded cable
Voltage Monitor Yes
PCB Temperature Monitor Yes
CPU Temperature Monitor No
Dimensions Ø 404mm, height 175mm (without mount)
License Level 3
Operating System RouterOS
CPU QCA9557-AT4A-R
Max Power Consumption 9W
Supported input voltage 11 V - 60 V
